سوئیچ شبکه غیرمدیریتی با 24 پورت گیگابیت و 4 پورت کامبو فیبرنوری گیگابیت
پارت نامبر:
ITT-SW-24GE4SFP
سوییچ شبکه تجاری
SW
ETH Switch
پورت فیبر نوری
4
SFP
پورت اترنت شبکه
24
Gigabit ETH
مشاوره تخصصی پیش از خرید
ارسال سریع به سراسر کشور
تضمین کیفیت و اصالت کالا
امکان بازگشت در صورت مشکل
پشتیبانی و پاسخگویی مداوم
توضیحات محصول
جزئیات محصول
| Technical Specifications | Description |
|---|---|
| Technical Specifications | ITT-SW-24GE4SFP |
| 10M/100M/1G RJ45 copper ports | 24 |
| Gigabit RJ45 and SFP Combo | 4 Combo |
| Performance Specification | * |
| Packet buffer memory | 2.1 Mb |
| Forwarding modes | Store-and-forward |
| Bandwidth | 64 Gbps |
| Packet forwarding rate | 47.62 Mpps (64-byte packet size) |
| MAC address database size | 8K (48-bit MAC addresses) |
| Jumbo frame support | 9K |
| IEEE Network Protocols | * |
| Protocols | • IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3z 1000BASE-X • IEEE 802.3az EEE • IEEE 802.3x Flow Control |
| Monitoring | * |
| LEDs | Yes |
| Per port | Speed, Link, Activity |
| Per device | Power |
| Physical Specifications | * |
| Dimensions (W × D × H) | 440 × 190 × 44.5 mm (17.32 × 7.48 × 1.75 in) |
| Weight | 2.2 kg (4.85 lb) |
| Max power | 15W (worst case, all ports used, line-rate traffic) |
| Idle power consumption | 8W (all ports link-down standby) |
| Energy Efficient Ethernet (EEE) | Yes (disabled by default) |
| Fan | Fanless |
| Environmental Specifications | * |
| Operating Temperature | -20°C to 55°C (-4°F to 131°F) |
| Operating Humidity | 95% RH max, non-condensing |
| Operating Altitude | 10,000 ft (3,000 m) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Storage Humidity | 95% RH max, non-condensing |
| Storage Altitude | 10,000 ft (3,000 m) |
| Electromagnetic Emissions and Immunity | * |
| Certifications | CE, FCC Part 15 Class A, VCCI Class A, EN 55022 Class A, EN 55024, CCC, ICES-003 Class A, ANSI C63.4:2014, IEC 60950-1:2005 + amendments |
| Safety | * |
| Safety Certifications | CB, CSA 22.2 #950, UL 1950/cUL IEC 950/EN 60950, EN 60950-1 + amendments, AN/NZS 60950.1:2015, CCC |
| Warranty and Support | * |
| Hardware Limited Warranty | Limited Lifetime* |
| Technical Support via Phone and Email | Limited Lifetime* |
| 24×7 Online Chat Technical Support | Limited Lifetime* |
| Package Contents | * |
| All models | Network Switch; AC power cord (C13); rack mounting brackets & screws; rubber SFP protection caps; installation guide |
| Business Type | Commercial |
| Bandwidth | 1G |
| More Filters | Unmanaged |
